Laminated 1/8″ Clear – 0.015″ Vanceva ® Evening Shadow (835000) PVB + 0.015″ Saflex ® Clear PVB – 1/8″ Clear Laminated 1/8″ Clear – 0.030″ Trosifol ® Soft White (2180) White PVB – 1/8″ Clear Laminated 1/8″ Clear – 0.030″ Trosifol ® Translucent White (2165) White PVB – 1/8″ Clear
Laminated 1/8″ Clear – 0.030″ Vanceva ® Arctic Snow (216500) White PVB – 1/8″ Clear Laminated 1/4″ Clear – 0.075″ StormGlass™ – 1/4″ Clear Laminated 1/4″ Clear – 0.100″ Saflex ® HP Clear PVB – 1/4″ Clear Laminated 1/4″ Clear – 0.090″ SentryGlas ® – 1/4″ Clear Laminated 1/4″ Clear – 0.060″ SentryGlas ® – 1/4″ Clear Laminated 1/4″ Clear – 0.035″ SentryGlas ® – 1/4″ Clear Laminated 1/4″ Clear – 0.090″ Clear PVB – 1/4″ Clear Laminated 1/4″ Clear – 0.060″ Clear PVB – 1/4″ Clear Laminated 1/4″ Clear – 0.030″ Clear PVB – 1/4″ Clear Laminated 3/16″ Clear – 0.100″ Saflex ® HP Clear PVB – 3/16″ Clear Laminated 1/8″ Clear – 0.075″ StormGlass™ – 1/8″ Clear Laminated 1/8″ Clear – 0.100″ Saflex ® HP Clear PVB – 1/8″ Clear Laminated 1/8″ Clear – 0.090″ SentryGlas ® – 1/8″ Clear Laminated 1/8″ Clear – 0.060″ SentryGlas ® – 1/8″ Clear Laminated 1/8″ Clear – 0.035″ SentryGlas ® – 1/8″ Clear Laminated 1/8″ Clear – 0.090″ Clear PVB – 1/8″ Clear Laminated 1/8″ Clear – 0.060″ Clear PVB – 1/8″ Clear Laminated 1/8″ Clear – 0.030″ Clear PVB – 1/8″ Clear For full details of the decorative interlayers including Vanceva ® Color, Pattern, Metallic and Image see the decorative section The tables below include a selection of the most common colors available. Mass pigmented and decorative interlayers can also be used to provide a wide range of effects.įor monolithic, laminated or insulating glass unit performance data, please go to SystemSelect ™, our on-line glass performance calculator. Laminated architectural glass can be fabricated using various glass types, including low-e, clear, low-iron, tinted, reflective, patterned or wired glass to achieve desired aesthetics or to improve solar control and thermal performance. Please contact Oldcastle BuildingEnvelope ® for product availability and performance data as this information is subject to change without notice. Oldcastle BuildingEnvelope ® offers a variety of glass products to meet your architectural glazing design needs. The glass types listed below are included in the Laminated Glass offering. Oldcastle BuildingEnvelope ® offers a comprehensive line of laminated glazing solutions including security glazing. Point supported laminates must be fully tempered.
(1) These products are recommended for point-supported canopies. These are conservative designs assuming the glass is horizontal with maximum snow load.ĭetailed engineering design particularly on sloped glazing can often increase the maximum allowable size. Without the equivalent design load, Oldcastle BuildingEnvelope ® must rely on the conservative limits recommended by the American Architectural Manufacturers Association (AAMA) for four-side uniform support. This calculation must take into account the correct combination of snow load (if applicable), wind load and dead load. However, it is the responsibility of the design professional to calculate and provide the equivalent design load. Oldcastle BuildingEnvelope ® can calculate the most suitable glass for use in any given application.
